    Terminal UI library for MoonBit with virtual DOM-based rendering.

    Supported targets: js, native

    #Features

    • Virtual DOM with diff-based ANSI rendering
    • Flexbox and CSS Grid layout (powered by mizchi/crater)
    • Reactive signals integration (mizchi/signals)
    • Styled UI components (@components)
    • Keyboard and mouse input handling

    alt text

    #Installation

    moon add mizchi/tui

    Or add it to your moon.mod directly:

    import { "mizchi/tui@0.10.2", }

    #Package Structure

    mizchi/tui/ ├── vnode/ # Virtual DOM primitives (row, column, view, grid, text) ├── components/ # Styled UI components (button, modal, table, etc.) ├── headless/ # State types (ButtonState, InputState, etc.) ├── events/ # Input parsing (KeyEvent, MouseEvent) ├── render/ # ANSI rendering engine ├── io/ # Platform I/O (terminal size, keypress) └── core/ # Low-level types (Component, Color)

    #Quick Start

    fn main {
    let node = @vnode.column(gap=1.0, padding=1.0, border="rounded", [
    @vnode.text("Hello, TUI!", fg="cyan", bold=true),
    @components.button("Click me"),
    @components.progress_bar(0.7),
    ])

    // Render to string
    let output = @vnode.render_vnode_once(80, 24, node)
    println(output)
    }

    #Layout Primitives (@vnode)

    // Flex containers
    @vnode.view([...]) // column by default
    @vnode.view(direction="row", [...]) // horizontal
    @vnode.row([...]) // shorthand for direction="row"
    @vnode.column([...]) // shorthand for direction="column"

    // Grid layout
    @vnode.grid(columns=[1.0, 2.0, 1.0], [...]) // 1fr 2fr 1fr
    @vnode.grid_item(column_span=2, child=...) // span multiple cells

    // Named grid areas
    @vnode.grid(
    areas=["header header", "sidebar main", "footer footer"],
    [
    @vnode.grid_area("header", header_content),
    @vnode.grid_area("sidebar", sidebar_content),
    @vnode.grid_area("main", main_content),
    @vnode.grid_area("footer", footer_content),
    ]
    )

    // Text
    @vnode.text("Hello", fg="cyan", bold=true)

    // Spacing
    @vnode.spacer() // flexible space
    @vnode.hspace(2.0) // horizontal space
    @vnode.vspace(1.0) // vertical space

    #Styled Components (@components)

    // Buttons
    @components.button("Submit", state=@headless.ButtonState::Focused)
    @components.icon_button("✕")
    @components.text_button("Learn more")

    // Form
    @components.checkbox("Remember me", true)
    @components.radio("Option A", true)
    @components.switch(true, "Dark mode")
    @vnode.input("value", placeholder="Enter text...")

    // Selection
    @components.listbox(items, selected_id)
    @components.tab_bar(tabs, selected_id)
    @components.combobox_trigger("Select...", open=false)

    // Feedback
    @components.progress_bar(0.5)
    @components.spinner(tick)
    @components.gauge("CPU", 0.75)
    @components.sparkline(data)

    // Modal
    @components.modal("Title", [...])
    @components.alert_dialog("Error occurred")
    @components.confirm_dialog("Delete?")

    // Dashboard
    @components.table(columns, rows)
    @components.stat("Users", "1,234")
    @components.meter("Memory", 0.8)

    #Layout Evaluation (experiments/eval_ui)

    The experiments/eval_ui package provides a layout regression harness and layout-rect snapshots (IDs only, auto/root filtered).

    # Base patterns moon -C experiments/eval_ui run . -- --layout-snapshot # Persona 5 patterns moon -C experiments/eval_ui run . -- --layout-snapshot-p5

    For running eval with layout-rect inference (no AA parsing), add --infer-layout:

    moon -C experiments/eval_ui run . -- --infer-layout

    Snapshots:
    • __snapshots__/eval_ui_layout.txt
    • __snapshots__/eval_ui_layout_p5.txt

    #Examples

    just run example=simple # Minimal counter app moon run examples/simple --target js # Run an example directly moon run examples/command-launcher --target js moon run examples/completion --target js moon run examples/components --target js moon run examples/editor --target js moon run examples/form --target js moon run examples/grid-area --target js moon run examples/grid-layout --target js moon run examples/kitty-graphics --target js moon run examples/roguelike --target js moon run examples/wizard --target js

    Note: The chat example moved to mizchi/vivebox.

    #Documentation

    See docs/tutorial.mbt.md for detailed API documentation.

    #License

    MIT

    A11yNode

    AccordionState

    Accordion panel state

    App

    using @mizchi/tui/render { type App }

    App manages the render loop and diff-based updates

    BorderChars

    Re-exports for convenient access to commonly used types and functions Users can import @tui and access most APIs from there.

    ButtonState

    Button state enum

    CharBuffer

    Character-based framebuffer

    CharCell

    A single character cell in the terminal

    Color

    using @mizchi/tui/core { type Color }

    Re-exports for convenient access to commonly used types and functions Users can import @tui and access most APIs from there.

    Component

    Re-exports for convenient access to commonly used types and functions Users can import @tui and access most APIs from there.

    DisplayValue

    Display value

    EditConfig

    Configuration for editable input behavior

    FocusContext

    Focus context for managing Tab navigation

    FocusNav

    Focus navigation helper for keyboard navigation

    GridAutoFlowValue

    Grid auto-flow value

    HitTestResult

    Hit test result

    InputEvent

    Input event

    InputResult

    Result of an input session

    InputState

    Input state for visual feedback

    KeyEvent

    Keyboard event

    KeyModifier

    Key modifiers

    ModalState

    Modal dialog state

    MouseButton

    Mouse button

    MouseEvent

    Mouse event

    MouseEventType

    Mouse event type

    RenderStyleMap

    Re-exports for convenient access to commonly used types and functions Users can import @tui and access most APIs from there.

    Role

    using @mizchi/tui/core { type Role }

    Re-exports for convenient access to commonly used types and functions Users can import @tui and access most APIs from there.

    SelectionState

    Selection state for single-select components

    SpecialKey

    Special keys

    TextContentMap

    Re-exports for convenient access to commonly used types and functions Users can import @tui and access most APIs from there.

    TextStyle

    Text style for writing text

    ToggleState

    Toggle state for checkbox/switch

    TuiEvent

    TUI Event - passed to event handlers

    TuiNode

    Type alias for luna Node with TuiEvent and TuiAttrValue

    VNodeApp

    VNodeApp manages the vnode render loop with diff-based updates

    ansi_full_reset

    fn ansi_full_reset() -> String

    Full terminal reset sequence for recovering from corrupted state

    cleanup_stdin

    fn cleanup_stdin() -> Unit

    Disable raw mode and restore terminal settings

    column

    fn column(id? : String, gap? : Double, margin? : Double, margin_x? : Double, margin_y? : Double, padding? : Double, padding_x? : Double, padding_y? : Double, width? : Double, height? : Double, min_width? : Double, min_height? : Double, flex_grow? : Double, justify? : String, align? : String, border? : String, border_color? : String, bg? : String, role? : String, tab_index? : Int, on_click? : (
    TuiEvent
    ) -> Unit?, children : Array[
    Node
    [
    TuiEvent
    ,
    TuiAttrValue
    ]]) ->
    Node
    [
    TuiEvent
    ,
    TuiAttrValue
    ]

    Column container (vertical flex)

    disable_mouse

    fn disable_mouse() -> String

    disable_mouse_all

    fn disable_mouse_all() -> String

    Disable mouse motion tracking

    dump_a11y_tree

    fn dump_a11y_tree(nodes : Array[
    A11yNode
    ]) -> String

    enable_mouse

    fn enable_mouse() -> String

    enable_mouse_all

    fn enable_mouse_all() -> String

    Enable mouse with motion tracking (reports move events even without button press)

    enable_raw_mode

    fn enable_raw_mode() -> Unit

    Enable raw mode for character-by-character input

    form_edit_config

    fn form_edit_config(field_name : String, signal :
    Signal
    [String], on_edit_start? : () -> Unit?, on_edit_end? : () -> Unit?, on_force_quit? : () -> Unit?) ->
    EditConfig

    Helper to create a standard edit config for form fields

    get_terminal_size

    fn get_terminal_size() -> (Int, Int)

    Get terminal size (columns, rows)

    grid

    fn grid(columns? : Array[Double], rows? : Array[Double], areas? : Array[String], auto_flow? : String, id? : String, gap? : Double, padding? : Double, padding_x? : Double, padding_y? : Double, width? : Double, height? : Double, border? : String, border_color? : String, bg? : String, role? : String, tab_index? : Int, children : Array[
    Node
    [
    TuiEvent
    ,
    TuiAttrValue
    ]]) ->
    Node
    [
    TuiEvent
    ,
    TuiAttrValue
    ]

    Grid container with CSS Grid layout Supports both explicit columns/rows and named areas

    grid_area

    Grid area - place child in a named grid area Used with grid(areas=[...]) for semantic layout

    grid_item

    Grid item with placement control (explicit column/row positioning)

    hspace

    Horizontal space with fixed width

    init_vnode_terminal

    fn init_vnode_terminal(width : Int, height : Int, output_fn : (String) -> Unit, mouse? : Bool, raw_mode? : Bool) -> (
    VNodeApp
    , () -> Unit)

    Initialize a VNodeApp with terminal setup and return a cleanup function.

    input

    fn input(value : String, id? : String, placeholder? : String, state? :
    InputState
    , fg? : String, bg? : String, placeholder_fg? : String, focus_border_color? : String, edit_border_color? : String, disabled_fg? : String, disabled_bg? : String, width? : Double, min_width? : Double, padding_x? : Double, padding_y? : Double) ->
    Node
    [
    TuiEvent
    ,
    TuiAttrValue
    ]

    Create an input component

    input_plain

    fn input_plain(value : String, placeholder? : String, state? :
    InputState
    , fg? : String, placeholder_fg? : String) ->
    Node
    [
    TuiEvent
    ,
    TuiAttrValue
    ]

    Create an input field without border (inline style)

    is_printable_char

    fn is_printable_char(c : Char) -> Bool

    Check if a character is printable (for IME input detection)

    is_printable_string

    fn is_printable_string(s : String) -> Bool

    Check if a string is all printable characters (for IME input detection)

    parse_input

    fn parse_input(input : String) ->
    InputEvent

    Parse escape sequence
    fn print_raw(s : String) -> Unit

    Print string to stdout without newline

    read_key

    fn read_key() -> String

    Read a single key from stdin (raw mode) Returns the key as a string (may be escape sequence)

    render_once

    fn render_once(width : Int, height : Int, component :
    Component
    ) -> String

    Simple render function for one-shot rendering (no reactivity)

    render_vnode_once

    fn render_vnode_once(width : Int, height : Int, root :
    Node
    [
    TuiEvent
    ,
    TuiAttrValue
    ]) -> String

    Simple render function for one-shot rendering (no reactivity)

    resolve_button_state

    fn resolve_button_state(id : String, hover_id : String, focus? :
    FocusNav
    ?, disabled? : Bool) ->
    ButtonState

    Resolve button state from hover_id and optional FocusNav

    row

    fn row(id? : String, gap? : Double, margin? : Double, margin_x? : Double, margin_y? : Double, padding? : Double, padding_x? : Double, padding_y? : Double, width? : Double, height? : Double, min_width? : Double, min_height? : Double, flex_grow? : Double, justify? : String, align? : String, border? : String, border_color? : String, bg? : String, role? : String, tab_index? : Int, on_click? : (
    TuiEvent
    ) -> Unit?, children : Array[
    Node
    [
    TuiEvent
    ,
    TuiAttrValue
    ]]) ->
    Node
    [
    TuiEvent
    ,
    TuiAttrValue
    ]

    Row container (horizontal flex)

    run

    fn run(render_fn : () ->
    Component
    , on_event : (
    InputEvent
    ) -> Bool, mouse? : Bool, on_hover? : (String) -> Unit?) -> Unit

    Run a TUI application with simplified lifecycle management. Handles terminal setup, event loop, and cleanup automatically.

    Parameters:
    • render_fn: Function that returns the component tree
    • on_event: Event handler that returns false to quit
    • mouse: Whether to enable mouse support (default: true)

    Example:
    @tui.run( fn() { @tui.text("Hello") }, fn(event) { if event.is_quit() { false } else { true } }, )

    run_vnode_app

    fn run_vnode_app(width : Int, height : Int, render_fn : () ->
    Node
    [
    TuiEvent
    ,
    TuiAttrValue
    ], output_fn : (String) -> Unit) -> (() -> Unit)

    Full-screen vnode app helper: sets up alt screen and handles cleanup

    start_edit

    fn start_edit(config :
    EditConfig
    , current_value : String, on_complete : () -> Unit, confirm_on_shift_enter? : Bool, esc_cancels? : Bool) -> Unit

    Start editing a field with cooked mode (IME support) This exits alternate screen temporarily for proper IME input confirm_on_shift_enter: if true, Shift+Enter confirms and Enter inserts newline esc_cancels: if false, Esc is ignored

    start_edit_inplace

    fn start_edit_inplace(config :
    EditConfig
    , current_value : String, row : Int, col : Int, width : Int, height : Int, multiline : Bool, on_complete : () -> Unit, confirm_on_shift_enter? : Bool, esc_cancels? : Bool, on_lines_change? : (Int) -> Int?, on_completion? : (String, Int) -> String??) -> Unit

    Start editing a field inplace (stays in TUI screen) row/col are 1-indexed ANSI coordinates width/height define the input area (supports multi-line wrapping) multiline: if true, Enter can insert newline when confirm_on_shift_enter is true confirm_on_shift_enter: if true, Shift+Enter confirms esc_cancels: if false, Esc is ignored on_lines_change: optional callback (line_count) -> new_height for dynamic resizing on_completion: optional callback (text, cursor_pos) -> completion_suffix for Tab completion

    start_edit_inplace_in_bounds

    fn start_edit_inplace_in_bounds(config :
    EditConfig
    , current_value : String, bounds :
    HitTestResult
    , multiline : Bool, on_complete : () -> Unit, confirm_on_shift_enter? : Bool, esc_cancels? : Bool, border? : Int, on_lines_change? : (Int) -> Int?, on_completion? : (String, Int) -> String??) -> Unit

    Start editing within bounds (HitTestResult) with border adjustment. bounds.x/y are 0-indexed; row/col for ANSI are 1-indexed. on_completion: optional callback (text, cursor_pos) -> completion_suffix for Tab completion

    start_keypress_listener

    fn start_keypress_listener(handler : (String) -> Unit) -> Unit

    Start keypress listener (raw mode) - blocks until stop_keypress_listener is called This provides the same interface as JS where the listener runs until stopped If called from within a handler (e.g., from restore_tui), just updates the handler

    stop_keypress_listener

    fn stop_keypress_listener() -> Unit

    Stop keypress listener

    text

    fn text(content : String, fg? : String, bold? : Bool, underline? : Bool, role? : String) ->
    Node
    [
    TuiEvent
    ,
    TuiAttrValue
    ]

    Static text node

    text_dyn

    fn text_dyn(getter : () -> String, fg? : String, bold? : Bool, underline? : Bool, role? : String) ->
    Node
    [
    TuiEvent
    ,
    TuiAttrValue
    ]

    Dynamic text node

    textarea

    fn textarea(value : String, id? : String, placeholder? : String, state? :
    InputState
    , rows? : Int, fg? : String, bg? : String, placeholder_fg? : String, focus_border_color? : String, edit_border_color? : String, min_width? : Double, padding_x? : Double, padding_y? : Double) ->
    Node
    [
    TuiEvent
    ,
    TuiAttrValue
    ]

    Create a textarea component (multi-line input)

    view

    fn view(direction? : String, id? : String, gap? : Double, margin? : Double, margin_x? : Double, margin_y? : Double, padding? : Double, padding_x? : Double, padding_y? : Double, width? : Double, height? : Double, min_width? : Double, min_height? : Double, flex_grow? : Double, justify? : String, align? : String, border? : String, border_color? : String, bg? : String, role? : String, tab_index? : Int, on_click? : (
    TuiEvent
    ) -> Unit?, children : Array[
    Node
    [
    TuiEvent
    ,
    TuiAttrValue
    ]]) ->
    Node
    [
    TuiEvent
    ,
    TuiAttrValue
    ]

    Generic view container (flex layout with configurable direction) Default direction is column (React Native style)

    vspace

    Vertical space with fixed height

    Source Files
